Female RCAs

Female RCAs are stocked with the nut shown, but an alternate thick or thin nut is available to accommodate the thickness of most mounting surfaces. See the measurement chart at the bottom of this page.

Click on image to enlarge.

(click to view closeup of model CTFA) CTFA
RCA Female, non-magnetic, eutectic Brass, Gold plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA L Thin) GRFA L Thin
Long RCA female, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thin Brass nut, Gold plate.
(click to view closeup of model GRFA L Thick) GRFA L Thick
Long RCA female, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA S Thin) GRFA S Thin
Short RCA Female, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thin Brass nut, Gold plate.
(click to view closeup of model GRFA S Thick) GRFA S Thick
Short RCA Female, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA PRT Thick) GRFA PRT Thick
Right angle, PC board mount RCA, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA PRT) GRFA PRT
Right angle, PC board mount RCA, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thin Brass nut, Gold plate.
(click to view closeup of model GRFA PRT2) GRFA PRT2
Two piece, right angle, PC board mount RCA, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA DBL PRT) GRFA DBL PRT
Double RCA Female, right angle, PC board mount, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thin Brass nut, Gold plate.
(click to view closeup of model GRFA DBL PRT G) GRFA DBL PRT G
Double RCA Female, right angle, PC board mount, non-magnetic, eutectic Brass, Gold plate. Thin Brass nuts, Gold plate.
(click to view closeup of model GRFA PSR2) GRFA PSR2
Straight, PC board mount RCA, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA PSR2 M) GRFA PSR2 M
Straight, PC board mount, Female RCA. This part is the same as the GRFA PSR, except the flange is set back to accommodate thicker mounting panels and various PC boards. Non- magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA PS Thick) GRFA PS Thick
Straight, PC board mount RCA, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.
(click to view closeup of model GRFA PS) GRFA PS
Straight, PC board mount RCA, non-magnetic, eutectic Brass, Rhodium over Silver plate. Thin Brass nut, Gold plate.
(click to view closeup of model GRFA PS2) GRFA PS2
Two piece, straight, PC board mount RCA, non- magnetic, eutectic Brass, Rhodium over Silver plate. Thick Brass nut, Gold plate.

Different combinations of RCA thread lengths and mounting nut thicknesses will accommodate most mounting plates

Short threads/thick nut = 0.0" to .082"
Short threads/thin nut = .079" to .142"
Long threads/thick nut = .142" to .350"
Long threads/thin nut = .350" to .400"
An additional .037" can be gained by removing the internal washer, grounding the connector.
